CLOUDCORE ROUTER, CPU 72 NÚCLEOS , 1 PUERTO GIGABIT ETHERNET, 8 PUERTOS SFP/SFP+, 16 GB MEMORIA-Networking-MIKROTIK-Bsai Seguridad & Controles

Descripción

CCR1072-1G-8S+

Name: CLOUDCORE ROUTER, CPU 72 NÚCLEOS , 1 PUERTO GIGABIT ETHERNET, 8 PUERTOS SFP/SFP+, 16 GB MEMORIA
Brand: MIKROTIK
SKU: CCR1072-1G-8S+
Price: 96999.20 MXN
Availability: OutOfStock

Router estrella, el CCR1072, es alimentado por una CPU Tilera de 72 núcleos, cada núcleo tiene una velocidad de 1 GHz, y para utilizar completamente este poder, el CCR1072 está equipado con ocho puertos 10G SFP+ conectados de forma independiente.

La unidad viene equipada con instalacion de RouterOS L6, 16 GB de RAM ECC incorporado, pantalla táctil LCD a color, dos fuentes de alimentación desmontables (hotplug) para la redundancia, ranura para tarjeta inteligente, microUSB, USB de tamaño regular, microSD y 2x M.2 ranuras para almacenamiento adicional .

Gracias al procesador 72 de núcleo único y puertos que están conectados directamente a la CPU, CCR1072 es capaz de más de 120 millones de paquetes por segundo de rendimiento.

Características principales de RouterOS

Specifications

Details
Product code	CCR1072-1G-8S+
Architecture	TILE
CPU	TLR4-07280
CPU core count	72
CPU nominal frequency	1 GHz
Dimensions	443x315x44mm
License level	6
Operating System	RouterOS
Size of RAM	16 GB
Storage size	128 MB
Storage type	NAND
Tested ambient temperature	-20°C to 60°C

Powering

Details
Number of AC inputs	2
AC input range	100-240
Max power consumption	125 W

Ethernet

Details
10/100/1000 Ethernet ports	1

Fiber

Details
SFP+ ports	8

Peripherals

Details
Memory card type	microSD, 2x M.2
Memory Cards	3
Serial port	RJ45
Number of USB ports	2
USB Power Reset	Yes
USB slot type	microUSB type AB; USB type A
Max USB current (A)	1
Smart card slot	Yes

Other

Details
CPU temperature monitor	Yes
Current Monitor	Yes
PCB temperature monitor	Yes
Voltage Monitor	Yes

Accesorios Incluidos:

Ethernet test results

CCR1072-1G-8S+		Tile 72 Core (1200Mhz, DDR1333) Max possible throughput
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	6,502.0	78,960.3	18,790.0	76,963.8	119,047.6	60,952.4
Bridging	25 bridge filter rules	6,130.5	74,448.8	8,192.7	33,557.3	10,339.5	5,293.8
Routing	none (fast path)	6,502.0	78,960.3	18,790.0	76,963.8	86,507.0	44,291.6
Routing	25 simple queues	6,502.0	78,960.3	12,370.4	50,669.2	13,474.2	6,898.8
Routing	25 ip filter rules	4,667.6	56,683.3	5,985.1	24,515.0	5,873.8	3,007.4

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

Especificaciones

Nombre: CLOUDCORE ROUTER, CPU 72 NÚCLEOS , 1 PUERTO GIGABIT ETHERNET, 8 PUERTOS SFP/SFP+, 16 GB MEMORIA

Fabricante: MIKROTIK

Calificación:

Identificador del producto: CCR1072-1G-8S+

Código fiscal: 43222609

Peso kg: 9 kg

Garantía de fábrica: 12 Meses (salvo se indique lo contrario en la descripción del producto).

Admite devoluciones:

Documentación

CLOUDCORE ROUTER, CPU 72 NÚCLEOS , 1 PUERTO GIGABIT ETHERNET, 8 PUERTOS SFP/SFP+, 16 GB MEMORIA

Marca: MIKROTIK

Tipo: Networking

SKU: CCR1072-1G-8S+

Agotado

$ 96,999.20 MXN

$ 96,999.20 MXN Precio regular: ~~$ 126,900.00 MXN~~

Precios en MXN con IVA incluido.
