INYECTOR HUB ADMINSITRABLE ULTRA POE 802.3AF/AT 8 PUERTOS GIGABIT, POTENCIA 400W [UPOE-800G]
INYECTOR HUB ADMINSITRABLE ULTRA POE 802.3AF/AT 8 PUERTOS GIGABIT, POTENCIA 400W [UPOE-800G]
Lo más destacado:
- 8 puertos Gigabit con Ultra PoE
- Hasta 60 W por puerto
- Presupuesto PoE total de 400 W
Agotado
Otras opciones similares:
No se pudo cargar la disponibilidad de recolección
Descripción
Descripción

La serie de concentrador de inyector administrado Ultra PoE de Planet , una solución Ultra PoE rentable y rápida, está diseñada para actualizar perfectamente una infraestructura de red existente a un sistema de red Ultra Power sobre Ethernet sin reemplazar el conmutador Ethernet existente. Modelo UPOE-800G de Planet. Le ayuda a que su red quede ordenada y funcionando como usted la necesita.
- 8-puertos 10/100/1000Mbps “Data input”
- 8-puertos 10/100/1000Mbps “Data + Power output”
- Complies with the IEEE 802.3, IEEE 802.3u and IEEE 802.3ab Ethernet standard
- One 10/100/1000BASE-T management port
- Ultra Power over Ethernet end-span/mid-span PSE
- Up to 60 watts of power on 4-pair UTP
- Backward compatible with IEEE 802.3at/af PD device
- 54V DC, 60-watt PoE power output at maximum on each port
- 400-watt PoE budget
- Auto-detection of IEEE 802.3at/af PoE equipment and device to avoid possible damage by incorrect installation
- Circuit protection prevents power interference between ports
- Remote power feeding up to 100m
- PoE Management: Per port PoE power schedule; PoE function enable/disable; Per port PoE function enable/disable; PoE port power feeding priority; PD classification detection; Over temperature protection; PD alive check; PoE schedule.
- Web interface for remote management
- Supports Network Time Protocol (NTP)
- Firmware upgrade through Web interface
- PLANET Smart Discovery utility automatically finds PLANET devices on the network
- SNMP trap for alarm notification of events
- System log/remote syslog
- 19-inch rack mountable; 1U height
- Reset button for resetting to default setting and system reboot
- LED indicators for PoE ready and PoE activity
- LED indicators for power alert and fan alert
- LED indicators for PoE power usage status (watts)
- FCC Part 15 Class A, CE
- Power over Ethernet
- PoE Standard
- IEEE 802.3af Power over EthernetIEEE 802.3at Power over Ethernet Plus4-pair Ultra PoE
- PoE Power Supply Type
- End-span/Mid-span/UPoE(Ultra PoE)
- Power Pin Assignment
- Pair 1 end-span: 1/2(-), 3/6(+)Pair 2 mid-span: 4/5(+), 7/8(-)UPoE: 1/2(-), 3/6(+),4/5(+), 7/8(-)
- PoE Power Output
- DC 54V/60-watt PoE via 4-pairDC 54V/30-watt PoE via 2-pair
- PoE Power Budget
- 400 watts/1364BTU
- Number of 60W PDs can be powered
- 6
- Number of 802.3af PDs (Class 0, 1, 2, 3) can be powered
- 8
- Number of 802.3at PDs (Class 1, 2, 3) can be powered
- 8
- Number of 802.3at PDs (Class 0, 4) can be powered
- 8
- Power Requirements
- 100-240V AC, 50/60 Hz, 6.5A
- Power Consumption
- 520 watts (max.)/1774BTU
- Ventilation
- Fan x 3
- Dimensions (W x D x H)
- 440 x 300 x 44.5 mm, 1U height
- Enclosure
- Metal
- Weight
- 4.2kg
Consejo del instalador
Planee la ubicación pensando en la ventilación y en el orden del cableado, y etiquete cada cable; le ahorrará tiempo en cualquier mantenimiento futuro.
Especificaciones técnicas
| Modelo | UPOE-800G |
| Marca | Planet |
Listo para implementar energía de próxima generación a través de EthernetEl UPOE-800G es un concentrador de inyector Ultra PoE administrado en rack de alta densidad con funciones PoE inteligentes PLANET a través de la interfaz de usuario web para la administración remota. Proporciona 8 10 / 100 / 1000BASE-T puertos Ethernet que ofrece ultra PoEinyector con un presupuesto PoE total de 400 vatios. Cada puerto PoE puede entregar hasta 60 vatios de potencia sobre Cat.5 / 5e / 6 cables Ethernet UTP que permiten que los datos y la potencia se transmitan simultáneamente a un dispositivo remoto de 60W y 802.3at / af (PD). La UPOE-800G permite la centralización de la fuente de alimentación y optimiza la instalación y la administración de energía de los dispositivos de red remotos, y proporciona una solución de red Power over Ethernet rápida, segura y rentable para pequeñas empresas y empresas. Despliegue rápido y fácil de la red PoEEl UPOE-800G se instala entre un conmutador Ethernet regular y los PD. Hay 16 puertos RJ45 STP en el panel frontal de la UPOE-800G, de los cuales los 8 puertos están en la pila inferior funcionan como " Entrada de datos "."mientras que los otros 8 puertos están en la pila superior funcionan como" PoE (datos y potencia) ". Tanto la potencia como los datos se transfieren simultáneamente a través de los cables UTP a las PD sin afectar el rendimiento y las funciones de la red existente.

Especificaciones
Especificaciones
Nombre: INYECTOR HUB ADMINSITRABLE ULTRA POE 802.3AF/AT 8 PUERTOS GIGABIT, POTENCIA 400W [UPOE-800G]
Fabricante: PLANET
Calificación:
Identificador del producto: UPOE-800G
Código fiscal: 43222600
Peso kg:
Garantía de fábrica: 3 años
Admite devoluciones: Si
