CPE DE EXTERIOR DE 5 GHZ A 150MBPS, ANTENA DIRECCIONAL DE 23DBI, POTENCIA DE 23 DBM, POE PASIVO-Enlaces PtP y PtMP-TP-LINK-Bsai Seguridad & Controles

CPE DE EXTERIOR DE 5 GHZ A 150MBPS, ANTENA DIRECCIONAL DE 23DBI, POTENCIA DE 23 DBM, POE PASIVO

Descripción

Especificaciones

CARACTERÍSTICAS DE HARDWARE

Procesador: Qualcomm 560MHz CPU, MIPS 74Kc
Memoria: 64MB DDR2 RAM, 8MB Flash
Interface: 1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button
Fuente de Alimentación: Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Dimensiones (W X D X H): 350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
Ganancia de Antena: 23dBi
Cobertura de Antena: 7°(Azimuth), 10°(Elevation)
Protección: 15KV ESD Protection 6KV Lightning Protection
Cercado: Material: Outdoor PC stabilized plastic Weatherproof: IP65 water and dust proof design

CARACTERÍSTICAS INALÁMBRICAS

Estándares Inalámbricos: IEEE 802.11a/n
Protocolo Propietario: TDMA Mode (with Pharos MAXtream enabled)
Velocidades Inalámbricas: Up to 150Mbps (40MHz, Dynamic) Up to 72.2Mbps (20MHz, Dynamic) Up to 36.1Mbps (10MHz, Dynamic) Up to 18.05Mbps (5MHz, Dynamic)
Frecuencia: 5.15~5.85GHz
Potencia de Transmisión: Max. 23dBm (Adjustable power by 1dBm)

CARACTERÍSTICAS DE SOFTWARE

IPv6: Yes
Configuración De Red: WAN: Static/Dynamic/PPPoE/L2TP/PPTP LAN: Static/Dynamic/DHCP Forwarding: ALG/UPnP/Virtual Server/Port Trigger Security: SPI Firewall/ Ping Forbidden/DoS Protection Access Control Static Routing Bandwidth Control IP & MAC Binding
Configuraciones Inalámbricas: Pharos MAXtream TDMA Technology Selectable Channel Width: 5/10/20/40MHz Auto Channel Selection Transmit Power Control Dynamic Frequency Selection(DFS) WDS Enable/Disable Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption SSID Broadcast Enable/Disable Multi-SSID with VLAN Tagging(AP Mode only) Distance/ACK Timeout Setting Wireless MAC Address Filter Wireless Advanced: Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Administración: Discovery and Remote Management via Pharos Control application HTTP/HTTPS Web-based management System log SNMP Agent(v2c) Ping Watch Dog Dynamic DDNS SSH Server
Herramientas de sistema: Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP Spectrum Analyzer Speed Test Ping Traceroute
Optimizaciones a Nivel de Sistema: Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog

POE ADAPTER FEATURES

Dimensions(W x D x H): 85.8×43.9×29.7 mm
Interfaces: 1 AC Jack with Earth Ground 1 10/100Mbps Shielded Ethernet Port (Power + Data) 1 10/100Mbps Shielded Ethernet Port (Data)
Botón: Remote Reset Button
Power Status LEDs: Green
Input: 100-240VAC, 50/60Hz
Output: 24VDC, 0.6A Max +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Eficiencia: >84.29%
Certifications: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark

OTROS

Certificación: CE, FCC, RoHS, IP65
Contenidos del Paquete: Outdoor Wireless CPE 24V 0.5A Passive PoE Adapter Pole Mounting Straps AC Power Cord Installation Guide
Requisitos del Sistema: Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux. Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Ambiente: Operating Temperature: -40°C~70°C (-40°F~158°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~95% non-condensing

CARACTERÍSTICAS DE HARDWARE
Procesador	Qualcomm 560MHz CPU, MIPS 74Kc
Memoria	64MB DDR2 RAM,8MB Flash
Interface	1 10/100Mbps Shielded Ethernet Port (LAN/POE) 1 Reset Button
Fuente de Alimentación	Passive Power over Ethernet via LAN (+4,5pins; -7,8pins) Voltage range: 16-27VDC
Dimensiones (W X D X H)	350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)
Ganancia de Antena	23dBi
Cobertura de Antena	7°(Azimuth), 10°(Elevation)
Protección	15KV ESD Protection 6KV Lightning Protection
Cercado

Especificaciones

Nombre: CPE DE EXTERIOR DE 5 GHZ A 150MBPS, ANTENA DIRECCIONAL DE 23DBI, POTENCIA DE 23 DBM, POE PASIVO

Fabricante: TP-LINK

Calificación:

Identificador del producto: CPE605

Código fiscal: 43222640

Peso kg: 1.4 kg

Garantía de fábrica: 12 Meses (salvo se indique lo contrario en la descripción del producto).

Admite devoluciones: Si

Documentación

CPE DE EXTERIOR DE 5 GHZ A 150MBPS, ANTENA DIRECCIONAL DE 23DBI, POTENCIA DE 23 DBM, POE PASIVO

Name: CPE DE EXTERIOR DE 5 GHZ A 150MBPS, ANTENA DIRECCIONAL DE 23DBI, POTENCIA DE 23 DBM, POE PASIVO
Brand: TP-LINK
SKU: CPE605
Price: 1206.50 MXN
Availability: InStock

Marca: TP-LINK

Tipo: Enlaces PtP y PtMP

SKU: CPE605

Su ahorro 21%

$ 1,206.50 MXN

$ 1,206.50 MXN Precio regular: ~~$ 1,532.00 MXN~~

Precios en MXN con IVA incluido.

¡Envío sin costo a todo México en pedidos mayores a 500 MXN!

Disponible en inventario 135 piezas

¿Es usted instalador o integrador?

Acceda a precios preferenciales de distribuidor y obtenga beneficios exclusivos.
